Image is for reference only , See Product Specifications
1856168
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 1856168 |
| Description: | TERM BLOCK 1POS SIDE ENTRY PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Green |
| Pitch | - |
| Series | COMBICON MKDSP |
| Current | 160A |
| Voltage | 600V |
| Features | Flange |
| Packaging | Bulk |
| Wire Gauge | 2/0-16 AWG |
| Part Status | Active |
| Screw Thread | M6 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.62 Nm (5.5 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Rising Cage Clamp |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Polyamide (PA), Nylon |
| Positions Per Level | 1 |
| Operating Temperature | - |
| Clamp Material - Plating | - |
| Screw Material - Plating | - |
| Contact Material - Plating | Tin Plated |
In Stock 51 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $9.33 | $9.14 | $8.96 |
