Image is for reference only , See Product Specifications
1751345
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 1751345 |
| Description: | TERM BLK 12P SIDE ENT 3.5MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Green |
| Pitch | 0.138" (3.50mm) |
| Series | COMBICON MKDS |
| Current | 10A |
| Voltage | 300V |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | 16-30 AWG |
| Part Status | Active |
| Screw Thread | M2 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.22-0.25 Nm (1.9-2.2 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Rising Cage Clamp |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Polyamide (PA), Nylon |
| Positions Per Level | 12 |
| Operating Temperature | - |
| Clamp Material - Plating | - |
| Screw Material - Plating | - |
| Contact Material - Plating | - |
In Stock 359 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $7.15 | $7.01 | $6.87 |
Request Quote
