Image is for reference only , See Product Specifications
1733033
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 1733033 |
| Description: | TERM BLOCK 3POS 35DEG 7.5MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Green |
| Pitch | 0.295" (7.50mm) |
| Series | COMBICON GSMKDS |
| Current | 15A |
| Voltage | 300V |
| Features | Interlocking (Side) |
| Packaging | Bulk |
| Wire Gauge | 12-30 AWG |
| Part Status | Active |
| Screw Thread | M3 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.5-0.6 Nm (4.4-5.3 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Rising Cage Clamp |
| Mating Orientation | 35° (145°) Angle with Board |
| Dielectric Material | Polyamide (PA), Nylon |
| Positions Per Level | 3 |
| Operating Temperature | - |
| Clamp Material - Plating | - |
| Screw Material - Plating | - |
| Contact Material - Plating | - |
In Stock 81 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.14 | $4.06 | $3.98 |
