Image is for reference only , See Product Specifications
1709460
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | 1709460 |
| Description: | TERM BLOCK PLUG 4POS STR 2.5MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug, Female Sockets |
| Color | White |
| Pitch | 0.098" (2.50mm) |
| Series | COMBICON PTSM |
| Features | Latches |
| Packaging | Bulk |
| Part Status | Active |
| Current - UL | 5A |
| Voltage - UL | 150V |
| Current - IEC | 6A |
| Mounting Type | Free Hanging (In-Line) |
| Voltage - IEC | 160V |
| Plug Wire Entry | 180° |
| Number of Levels | 1 |
| Termination Style | Screwless - Leg Spring, Push-In Spring |
| Header Orientation | - |
| Number of Positions | 4 |
| Positions Per Level | 4 |
| Contact Mating Finish | Tin |
| Operating Temperature | - |
| Wire Gauge or Range - AWG | 20-26 AWG |
| Wire Gauge or Range - mm² | 0.14-0.5mm² |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.44 | $1.41 | $1.38 |
