Image is for reference only , See Product Specifications
1688825
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | 1688825 |
| Description: | CONN D-TYPE RCPT 5POS R/A SLDR |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Color | Green |
| Pitch | 0.138" (3.50mm) |
| Series | POWER SUBCON |
| Features | Board Lock, DB15 Shape, Mating Flange |
| Packaging | Bulk |
| Screw Size | - |
| Part Status | Active |
| Current - IEC | 8A |
| Mounting Type | Through Hole |
| Voltage - IEC | 250V |
| Torque - Screw | - |
| Plug Wire Entry | - |
| Contact Material | Copper Alloy |
| Number of Levels | 1 |
| Insulation Height | 0.539" (13.70mm) |
| Termination Style | Solder |
| Wire Strip Length | - |
| Header Orientation | 90°, Right Angle |
| Ingress Protection | - |
| Contact Tail Length | 0.138" (3.50mm) |
| Dielectric Material | Polyamide (PA), Nylon |
| Number of Positions | 5 |
| Positions Per Level | 5 |
| Contact Mating Finish | Tin |
| Operating Temperature | -20°C ~ 80°C |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | UL94 V-0 |
In Stock 3 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $20.17 | $19.77 | $19.37 |
