Image is for reference only , See Product Specifications

1681185

Manufacturers: Phoenix Contact
Product Category: Circular Connectors
Data Sheet: 1681185
Description: CONN RCPT FMALE 4POS SOLDER CUP
RoHS status: RoHS Compliant
Attribute Attribute Value
Manufacturer Phoenix Contact
Product Category Circular Connectors
Color Black, Silver
Series SACC
Features Backshell, Coupling Nut
Packaging Bulk
Shielding -
Orientation A
Part Status Active
Termination Solder Cup
Applications -
Shell Finish Nickel
Cable Opening 0.138" ~ 0.197" (3.50mm ~ 5.00mm)
Mounting Type Free Hanging (In-Line)
Connector Type Receptacle, Female Sockets
Fastening Type Threaded
Shell Material Brass
Voltage Rating 30VAC/DC
Insert Material Polyamide (PA), Nylon
Shell Size, MIL -
Contact Material Copper Zinc
Mounting Feature -
Ingress Protection IP67 - Dust Tight, Waterproof
Number of Positions 4
Shell Size - Insert M8-4
Current Rating (Amps) 4A
Operating Temperature -40°C ~ 85°C
Contact Finish - Mating Gold
Backshell Material, Plating Polybutylene Terephthalate (PBT)
Material Flammability Rating UL94 HB
Contact Finish Thickness - Mating -

In Stock 22 pcs

Refrence Price ($) 1 pcs 100 pcs 500 pcs
$17.23 $16.89 $16.55

Request Quote
