Image is for reference only , See Product Specifications
1543647
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | 1543647 |
| Description: | CONN PLUG MALE 5POS GOLD SOLDER |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Circular Connectors |
| Color | Silver |
| Series | DSI |
| Features | - |
| Packaging | Bulk |
| Shielding | - |
| Orientation | B |
| Part Status | Active |
| Termination | Solder |
| Applications | - |
| Shell Finish | Nickel |
| Cable Opening | - |
| Mounting Type | Panel Mount, Through Hole |
| Connector Type | Plug, Male Pins |
| Fastening Type | Push-Twist |
| Shell Material | Zinc Die Cast |
| Voltage Rating | 60V |
| Insert Material | Polyamide (PA66), Nylon 6/6 |
| Shell Size, MIL | - |
| Contact Material | Copper Zinc |
| Mounting Feature | Bulkhead - Front Side Nut |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Number of Positions | 5 |
| Shell Size - Insert | M12-5 |
| Current Rating (Amps) | 4A |
| Operating Temperature | -25°C ~ 85°C |
| Contact Finish - Mating | Gold |
| Backshell Material, Plating | - |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Mating | - |
In Stock 11 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $16.69 | $16.36 | $16.03 |
