Image is for reference only , See Product Specifications
1521601
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | 1521601 |
| Description: | CONN RCPT FMALE 4POS GOLD IDC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Circular Connectors |
| Color | Black, Silver |
| Series | SACC |
| Features | Backshell, Coupling Nut |
| Packaging | Bulk |
| Shielding | - |
| Orientation | A |
| Part Status | Active |
| Termination | IDC |
| Applications | - |
| Shell Finish | Nickel |
| Cable Opening | 0.157" ~ 0.315" (4.00mm ~ 8.00mm) |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Receptacle, Female Sockets |
| Fastening Type | Push-Twist |
| Shell Material | Zinc Die Cast |
| Voltage Rating | 250V |
| Insert Material | Thermoplastic Polyurethane (TPU) |
| Shell Size, MIL | - |
| Contact Material | Copper Tin |
| Mounting Feature | - |
| Ingress Protection | IP65/67 - Dust Tight, Water Resistant, Waterproof |
| Number of Positions | 4 |
| Shell Size - Insert | M12-4 |
| Current Rating (Amps) | 4A |
| Operating Temperature | -25°C ~ 80°C |
| Contact Finish - Mating | Gold |
| Backshell Material, Plating | Polyamide (PA6), Nylon 6 |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Mating | - |
In Stock 167 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $14.92 | $14.62 | $14.33 |
