Image is for reference only , See Product Specifications
1012266
| Manufacturers: | Phoenix Contact |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | 1012266 |
| Description: | TERM BLOCK PLUG 2POS 2.54MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Phoenix Contact |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug Housing for Female Sockets |
| Color | Black |
| Pitch | 0.100" (2.54mm) |
| Series | COMBICON MCC |
| Features | - |
| Packaging | Bulk |
| Screw Size | - |
| Part Status | Active |
| Current - UL | 6A |
| Voltage - UL | 150V |
| Current - IEC | 6A |
| Mounting Type | Free Hanging (In-Line) |
| Voltage - IEC | 160V |
| Torque - Screw | - |
| Plug Wire Entry | 180° |
| Contact Material | - |
| Number of Levels | 1 |
| Insulation Height | 0.156" (3.96mm) |
| Termination Style | Crimp |
| Wire Strip Length | 4.1-4.5mm |
| Header Orientation | - |
| Ingress Protection | - |
| Contact Tail Length | - |
| Dielectric Material | Polyamide (PA), Nylon |
| Number of Positions | 2 |
| Positions Per Level | 2 |
| Contact Mating Finish | - |
| Operating Temperature | -40°C |
| Wire Gauge or Range - AWG | 18-26 AWG |
| Wire Gauge or Range - mm² | 0.14 ~ 0.75mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 211 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.00 | $0.98 | $0.96 |
