Image is for reference only , See Product Specifications

DV14-206B-3K

Manufacturers:	Panduit Corp
Product Category:	Terminals - Quick Connects, Quick Disconnect Connectors
Data Sheet:	DV14-206B-3K
Description:	CONN QC RCPT 14-16AWG 0.187
RoHS status:	RoHS Compliant

Attribute	Attribute Value
Manufacturer	Panduit Corp
Product Category	Terminals - Quick Connects, Quick Disconnect Connectors
Color	Blue
Gender	Female
Series	Disco™
Features	Butted Seam, Serrated Termination
Packaging	Cut Tape (CT)
Tab Width	0.187" (4.75mm), 0.205" (5.21mm)
Insulation	Non-Mating End Insulated
Tab Length	-
Wire Gauge	14-16 AWG
Part Status	Active
Termination	Crimp
Mounting Type	Free Hanging (In-Line)
Tab Thickness	0.020" (0.51mm)
Terminal Type	Standard
Contact Finish	Tin
Contact Material	Brass
Length - Overall	0.770" (19.56mm)
Insulation Diameter	0.170" (4.32mm)
