| Manufacturer |
Panasonic Electronic Components |
| Product Category |
LED Indication - Discrete |
| Color |
Red, Green, Blue (RGB) |
| Series |
- |
| Features |
- |
| Lens Size |
1.30mm x 0.70mm |
| Packaging |
Digi-Reel® |
| Lens Color |
- |
| Lens Style |
Rectangle with Flat Top |
| Part Status |
Obsolete |
| Height (Max) |
0.35mm |
| Configuration |
Common Anode |
| Mounting Type |
Surface Mount |
| Viewing Angle |
- |
| Current - Test |
5mA Red, 5mA Green, 5mA Blue |
| Package / Case |
4-SMD, No Lead |
| Base Part Number |
LNJ757 |
| Size / Dimension |
1.30mm L x 1.05mm W |
| Lens Transparency |
- |
| Wavelength - Peak |
643nm Red, 520nm Green, 462nm Blue |
| Millicandela Rating |
30mcd Red, 90mcd Green, 15mcd Blue |
| Wavelength - Dominant |
628nm Red, 525nm Green, 470nm Blue |
| Supplier Device Package |
Chip LED |
| Voltage - Forward (Vf) (Typ) |
1.9V Red, 3V Green, 2.95V Blue |
