Image is for reference only , See Product Specifications
ELJ-PF4N7DF
| Manufacturers: | Panasonic Electronic Components |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | ELJ-PF4N7DF |
| Description: | FIXED IND 4.7NH 1.3A 100 MOHM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | PF |
| Ratings | - |
| Q @ Freq | 7 @ 100MHz |
| Packaging | Digi-Reel® |
| Shielding | Unshielded |
| Tolerance | ±0.3nH |
| Inductance | 4.7nH |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | 0402 (1005 Metric) |
| Material - Core | Ceramic |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) |
| DC Resistance (DCR) | 100mOhm Max |
| Current - Saturation | - |
| Current Rating (Amps) | 1.3A |
| Height - Seated (Max) | 0.022" (0.55mm) |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 0402 (1005 Metric) |
| Frequency - Self Resonant | 4.6GHz |
| Inductance Frequency - Test | 100MHz |
In Stock 16022 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
