Image is for reference only , See Product Specifications
EEH-ZS1H221V
| Manufacturers: | Panasonic Electronic Components |
|---|---|
| Product Category: | Aluminum - Polymer Capacitors |
| Data Sheet: | EEH-ZS1H221V |
| Description: | CAP ALUM POLY 220UF 20% 50V SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Product Category | Aluminum - Polymer Capacitors |
| Type | Hybrid |
| Series | ZS |
| Ratings | AEC-Q200 |
| Packaging | Tape & Reel (TR) |
| Tolerance | ±20% |
| Capacitance | 220µF |
| Part Status | Active |
| Applications | Automotive |
| Lead Spacing | - |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Voltage - Rated | 50V |
| Lifetime @ Temp. | 4000 Hrs @ 125°C |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.661" (16.80mm) |
| Operating Temperature | -55°C ~ 125°C |
| Surface Mount Land Size | 0.406" L x 0.406" W (10.30mm x 10.30mm) |
| Ripple Current @ Low Frequency | 555mA @ 100Hz |
| Ripple Current @ High Frequency | 3.7A @ 100kHz |
| ESR (Equivalent Series Resistance) | 13mOhm |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.43 | $1.40 | $1.37 |
