Image is for reference only , See Product Specifications
ECQ-E2105KB
| Manufacturers: | Panasonic Electronic Components |
|---|---|
| Product Category: | Film Capacitors |
| Data Sheet: | ECQ-E2105KB |
| Description: | CAP FILM 1UF 10% 250VDC RADIAL |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Product Category | Film Capacitors |
| Series | ECQ-E(B) |
| Ratings | - |
| Features | - |
| Packaging | Bulk |
| Tolerance | ±10% |
| Capacitance | 1µF |
| Part Status | Active |
| Termination | PC Pins |
| Applications | General Purpose |
| Lead Spacing | 0.492" (12.50mm) |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.602" L x 0.276" W (15.30mm x 7.00mm) |
| Dielectric Material | Polyester, Metallized |
| Voltage Rating - AC | - |
| Voltage Rating - DC | 250V |
| Height - Seated (Max) | 0.591" (15.00mm) |
| Operating Temperature | -40°C ~ 105°C |
In Stock 75 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.59 | $0.58 | $0.57 |
