Image is for reference only , See Product Specifications
ECQ-E1154KF
| Manufacturers: | Panasonic Electronic Components |
|---|---|
| Product Category: | Film Capacitors |
| Data Sheet: | ECQ-E1154KF |
| Description: | CAP FILM 0.15UF 10% 100VDC RAD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Product Category | Film Capacitors |
| Series | ECQ-E(F) |
| Ratings | - |
| Features | - |
| Packaging | Bulk |
| Tolerance | ±10% |
| Capacitance | 0.15µF |
| Part Status | Obsolete |
| Termination | PC Pins |
| Applications | General Purpose |
| Lead Spacing | 0.295" (7.50mm) |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.406" L x 0.177" W (10.30mm x 4.50mm) |
| Dielectric Material | Polyester, Metallized |
| Voltage Rating - AC | - |
| Voltage Rating - DC | 100V |
| Height - Seated (Max) | 0.335" (8.50mm) |
| Operating Temperature | -40°C ~ 105°C |
In Stock 24764 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.40 | $0.39 | $0.38 |
