Image is for reference only , See Product Specifications
2SK137400L
| Manufacturers: | Panasonic Electronic Components |
|---|---|
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Data Sheet: | 2SK137400L |
| Description: | MOSFET N-CH 50V 50MA SMINI-3 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Product Category | Transistors - FETs, MOSFETs - Single |
| Series | - |
| FET Type | N-Channel |
| Packaging | Digi-Reel® |
| Vgs (Max) | 10V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | SC-70, SOT-323 |
| Vgs(th) (Max) @ Id | 1.1V @ 100µA |
| Operating Temperature | 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 50Ohm @ 10mA, 2.5V |
| Power Dissipation (Max) | 150mW (Ta) |
| Supplier Device Package | SMini3-G1 |
| Drain to Source Voltage (Vdss) | 50V |
| Input Capacitance (Ciss) (Max) @ Vds | 4.5pF @ 5V |
| Current - Continuous Drain (Id) @ 25°C | 50mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V |
