25SEP33M+TSS
| Manufacturers: | Panasonic Electronic Components |
|---|---|
| Product Category: | Aluminum - Polymer Capacitors |
| Data Sheet: | 25SEP33M+TSS |
| Description: | CAP ALUM POLY 33UF 20% 25V T/H |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Product Category | Aluminum - Polymer Capacitors |
| Type | Polymer |
| Series | OS-CON™, SEP |
| Ratings | - |
| Packaging | Cut Tape (CT) |
| Tolerance | ±20% |
| Capacitance | 33µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | 0.138" (3.50mm) |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Voltage - Rated | 25V |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.472" (12.00mm) |
| Operating Temperature | -55°C ~ 105°C |
| Surface Mount Land Size | - |
| Ripple Current @ Low Frequency | 149mA @ 120Hz |
| Ripple Current @ High Frequency | 2.98A @ 100kHz |
| ESR (Equivalent Series Resistance) | 30mOhm |
In Stock 1036 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.79 | $1.75 | $1.72 |
