Image is for reference only , See Product Specifications
20SVPB22M
| Manufacturers: | Panasonic Electronic Components |
|---|---|
| Product Category: | Aluminum - Polymer Capacitors |
| Data Sheet: | 20SVPB22M |
| Description: | CAP ALUM POLY 22UF 20% 20V SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Product Category | Aluminum - Polymer Capacitors |
| Type | Polymer |
| Series | OS-CON™, SVPB |
| Ratings | - |
| Packaging | Cut Tape (CT) |
| Tolerance | ±20% |
| Capacitance | 22µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | - |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Voltage - Rated | 20V |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Height - Seated (Max) | 0.217" (5.50mm) |
| Operating Temperature | -55°C ~ 105°C |
| Surface Mount Land Size | 0.260" L x 0.260" W (6.60mm x 6.60mm) |
| Ripple Current @ Low Frequency | 100mA @ 120Hz |
| Ripple Current @ High Frequency | 2A @ 100kHz |
| ESR (Equivalent Series Resistance) | 35mOhm |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.64 | $1.61 | $1.58 |
