Image is for reference only , See Product Specifications
ADJ56024
| Manufacturers: | Panasonic Electric Works |
|---|---|
| Product Category: | Power Relays, Over 2 Amps |
| Data Sheet: | ADJ56024 |
| Description: | RELAY GEN PURPOSE DPDT 10A 24V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Panasonic Electric Works |
| Product Category | Power Relays, Over 2 Amps |
| Series | ADJ |
| Features | - |
| Coil Type | Non Latching |
| Packaging | Box |
| Relay Type | General Purpose |
| Part Status | Active |
| Seal Rating | Sealed - Fully |
| Coil Current | 10.4mA |
| Coil Voltage | 24VDC |
| Contact Form | DPDT (2 Form C) |
| Operate Time | 20ms |
| Release Time | 20ms |
| Mounting Type | Through Hole |
| Coil Insulation | - |
| Coil Resistance | 2.3 kOhms |
| Contact Material | Silver Tin Oxide (AgSnO), Gold (Au) |
| Switching Voltage | 250VAC - Max |
| Termination Style | PC Pin |
| Must Operate Voltage | 18 VDC |
| Must Release Voltage | 2.4 VDC |
| Operating Temperature | -40°C ~ 70°C |
| Contact Rating (Current) | 10A |
In Stock 13 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $19.85 | $19.45 | $19.06 |
