Image is for reference only , See Product Specifications
OA172AP-11-2WB
| Manufacturers: | Orion Fans |
|---|---|
| Product Category: | AC Fans |
| Data Sheet: | OA172AP-11-2WB |
| Description: | FAN AXIAL 172X50.8MM 115VAC WIRE |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Orion Fans |
| Product Category | AC Fans |
| RPM | 2400 RPM |
| Noise | 42.0 dB |
| Width | 50.80mm |
| Series | OA172AP |
| Weight | - |
| Air Flow | 170.0 CFM (4.76m³/min) |
| Fan Type | Tubeaxial |
| Features | - |
| Approvals | cURus, TUV |
| Part Status | Active |
| Termination | 2 Wire Leads |
| Bearing Type | Ball |
| Power (Watts) | 20.00W |
| Voltage Range | 80 ~ 130VAC |
| Static Pressure | 0.490 in H2O (122.1 Pa) |
| Voltage - Rated | 115VAC |
| Lifetime @ Temp. | 60000 Hrs @ 40°C |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Material - Frame | Aluminum |
| Size / Dimension | Rectangular/Rounded - 172mm L x 150mm H |
| Ingress Protection | - |
| Current Rating (Amps) | - |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $40.59 | $39.78 | $38.98 |
