Image is for reference only , See Product Specifications
SA203040
| Manufacturers: | On-Shore Technology, Inc. |
|---|---|
| Product Category: | Sockets for ICs, Transistors |
| Data Sheet: | SA203040 |
| Description: | CONN IC DIP SOCKET 20POS GOLD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | On-Shore Technology, Inc. |
| Product Category | Sockets for ICs, Transistors |
| Type | DIP, 0.3" (7.62mm) Row Spacing |
| Series | SA |
| Features | Open Frame |
| Packaging | Tube |
| Part Status | Active |
| Termination | Solder |
| Pitch - Post | 0.100" (2.54mm) |
| Mounting Type | Through Hole |
| Pitch - Mating | 0.100" (2.54mm) |
| Contact Resistance | 4mOhm |
| Dielectric Material | Thermoplastic, Polyester, Glass Filled |
| Contact Finish - Post | Gold |
| Current Rating (Amps) | 3A |
| Operating Temperature | -40°C ~ 105°C |
| Contact Finish - Mating | Gold |
| Contact Material - Post | Brass |
| Termination Post Length | - |
| Contact Material - Mating | Beryllium Copper |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | 80.0µin (2.03µm) |
| Contact Finish Thickness - Mating | Flash |
| Number of Positions or Pins (Grid) | 20 (2 x 10) |
In Stock 301 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.06 | $1.04 | $1.02 |
