Image is for reference only , See Product Specifications
OSTOQ067151
| Manufacturers: | On-Shore Technology, Inc. |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | OSTOQ067151 |
| Description: | TERM BLOCK HDR 6POS 90DEG 5MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | On-Shore Technology, Inc. |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Header, Male Pins, Shrouded (4 Side) |
| Color | - |
| Pitch | 0.197" (5.00mm) |
| Series | OSTOQ |
| Features | - |
| Packaging | Bulk |
| Screw Size | - |
| Part Status | Active |
| Voltage - UL | 300V |
| Current - IEC | - |
| Mounting Type | Solder |
| Torque - Screw | - |
| Plug Wire Entry | - |
| Contact Material | Brass |
| Number of Levels | 1 |
| Insulation Height | 0.157" (4.00mm) |
| Termination Style | - |
| Wire Strip Length | - |
| Header Orientation | 90°, Right Angle |
| Ingress Protection | - |
| Contact Tail Length | 0.157" (4.00mm) |
| Dielectric Material | Thermoplastic |
| Number of Positions | 6 |
| Positions Per Level | 6 |
| Contact Mating Finish | Tin |
| Operating Temperature | -40°C ~ 115°C |
| Wire Gauge or Range - AWG | - |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | - |
In Stock 9 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.01 | $0.99 | $0.97 |
