Image is for reference only , See Product Specifications
OSTHI220053
| Manufacturers: | On-Shore Technology, Inc. |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | OSTHI220053 |
| Description: | TERM BLOCK PLUG 22POS STR 5MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | On-Shore Technology, Inc. |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug, Female Sockets |
| Color | - |
| Pitch | 0.197" (5.00mm) |
| Series | OSTHI |
| Features | - |
| Packaging | Bulk |
| Screw Size | - |
| Part Status | Active |
| Voltage - UL | 300V |
| Current - IEC | - |
| Mounting Type | Free Hanging (In-Line) |
| Torque - Screw | - |
| Plug Wire Entry | - |
| Contact Material | Phosphor Bronze |
| Number of Levels | 1 |
| Insulation Height | - |
| Termination Style | Screwless - Spring Cage, Tension Clamp |
| Wire Strip Length | - |
| Header Orientation | - |
| Ingress Protection | - |
| Contact Tail Length | - |
| Dielectric Material | Thermoplastic |
| Number of Positions | 22 |
| Positions Per Level | 22 |
| Contact Mating Finish | - |
| Operating Temperature | -33°C ~ 105°C |
| Wire Gauge or Range - AWG | 12-28 AWG |
| Wire Gauge or Range - mm² | - |
| Material Flammability Rating | UL94 V-0 |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $9.11 | $8.93 | $8.75 |
