Image is for reference only , See Product Specifications
EDZ951/9
| Manufacturers: | On-Shore Technology, Inc. |
|---|---|
| Product Category: | Terminal Blocks - Headers, Plugs and Sockets |
| Data Sheet: | EDZ951/9 |
| Description: | TERM BLOCK PLUG 9POS STR 5.08MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | On-Shore Technology, Inc. |
| Product Category | Terminal Blocks - Headers, Plugs and Sockets |
| Type | Plug, Female Sockets |
| Color | Green |
| Pitch | 0.200" (5.08mm) |
| Series | EDZ951 |
| Features | - |
| Packaging | Bulk |
| Screw Size | - |
| Part Status | Active |
| Voltage - UL | 300V |
| Current - IEC | - |
| Mounting Type | Free Hanging (In-Line) |
| Torque - Screw | 0.5 Nm (4.4 Lb-In) |
| Plug Wire Entry | - |
| Contact Material | Copper |
| Number of Levels | 1 |
| Insulation Height | - |
| Termination Style | Screw |
| Wire Strip Length | 6mm |
| Header Orientation | - |
| Ingress Protection | - |
| Contact Tail Length | - |
| Dielectric Material | Polyamide (PA), Nylon |
| Number of Positions | 9 |
| Positions Per Level | 9 |
| Contact Mating Finish | - |
| Operating Temperature | -30°C ~ 105°C |
| Wire Gauge or Range - AWG | 12-22 AWG |
| Wire Gauge or Range - mm² | 2.5mm² |
| Material Flammability Rating | UL94 V-0 |
In Stock 84 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $7.71 | $7.56 | $7.40 |
