Image is for reference only , See Product Specifications
G2R-1-SN-DC12
| Manufacturers: | Omron Electronics Inc-EMC Div |
|---|---|
| Product Category: | Power Relays, Over 2 Amps |
| Data Sheet: | G2R-1-SN-DC12 |
| Description: | RELAY GEN PURPOSE SPDT 10A 12V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Omron Electronics Inc-EMC Div |
| Product Category | Power Relays, Over 2 Amps |
| Series | G2RS |
| Features | Lighted Indicator |
| Coil Type | Non Latching |
| Packaging | Bulk |
| Relay Type | General Purpose |
| Part Status | Obsolete |
| Seal Rating | - |
| Coil Current | 43.2mA |
| Coil Voltage | 12VDC |
| Contact Form | SPDT (1 Form C) |
| Operate Time | 15ms |
| Release Time | 5ms |
| Mounting Type | Socketable |
| Coil Insulation | - |
| Coil Resistance | 278 Ohms |
| Contact Material | - |
| Switching Voltage | 440VAC, 125VDC - Max |
| Termination Style | Plug In, Quick Connect - 0.187" (4.7mm) |
| Must Operate Voltage | 8.4 VDC |
| Must Release Voltage | 1.8 VDC |
| Operating Temperature | -40°C ~ 70°C |
| Contact Rating (Current) | 10A |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
