Image is for reference only , See Product Specifications
859-005-203R004
| Manufacturers: | NorComp Inc. |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | 859-005-203R004 |
| Description: | CONN PLUG FMALE 5POS GOLD SOLDER |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NorComp Inc. |
| Product Category | Circular Connectors |
| Color | Silver |
| Series | M12 |
| Features | - |
| Packaging | Tray |
| Shielding | Shielded |
| Orientation | A |
| Part Status | Active |
| Termination | Solder Cup |
| Applications | Industrial, Medical |
| Shell Finish | Nickel |
| Cable Opening | - |
| Mounting Type | Panel Mount |
| Connector Type | Plug, Female Sockets |
| Fastening Type | Threaded |
| Shell Material | Brass |
| Voltage Rating | 125V |
| Insert Material | Polybutylene Terephthalate (PBT) |
| Shell Size, MIL | - |
| Contact Material | Brass |
| Mounting Feature | Bulkhead - Front Side Nut |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Number of Positions | 5 |
| Shell Size - Insert | M12-5 |
| Current Rating (Amps) | 5A |
| Operating Temperature | -40°C ~ 85°C |
| Contact Finish - Mating | Gold |
| Backshell Material, Plating | - |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Mating | 10.0µin (0.25µm) |
In Stock 61 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $12.17 | $11.93 | $11.69 |
