| Manufacturer |
NorComp Inc. |
| Product Category |
D-Sub Connectors |
| Color |
White |
| Series |
Seal-D 774-E |
| Features |
Grounding Indents, Mounting Brackets |
| Packaging |
Tray |
| Wire Gauge |
- |
| Part Status |
Active |
| Termination |
Solder |
| Contact Form |
Machined |
| Contact Type |
Signal |
| Mounting Type |
Panel Mount, Through Hole, Right Angle |
| Connector Type |
Plug, Male Pins |
| Contact Finish |
Gold |
| Flange Feature |
Mating Side, Female Screwlock (4-40) |
| Number of Rows |
2 |
| Voltage Rating |
- |
| Backset Spacing |
0.370" (9.40mm) |
| Connector Style |
D-Sub |
| Contact Material |
Brass |
| Ingress Protection |
IP67 - Dust Tight, Waterproof |
| Dielectric Material |
Polyamide (PA6T), Nylon 6T |
| Number of Positions |
15 |
| Current Rating (Amps) |
5A |
| Operating Temperature |
-50°C ~ 100°C |
| Shell Material, Finish |
Steel, Nickel Plated |
| Contact Finish Thickness |
Flash |
| Material Flammability Rating |
UL94 V-0 |
| Shell Size, Connector Layout |
2 (DA, A) |
