Image is for reference only , See Product Specifications
200-015-263R001
| Manufacturers: | NorComp Inc. |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 200-015-263R001 |
| Description: | CONN D-SUB HD RCPT 15POS SMD R/A |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NorComp Inc. |
| Product Category | D-Sub Connectors |
| Color | Black |
| Series | 200 |
| Features | Board Lock, Shielded |
| Packaging | Tube |
| Wire Gauge | - |
| Part Status | Active |
| Termination | Solder |
| Contact Form | - |
| Contact Type | Signal |
| Mounting Type | Surface Mount, Right Angle |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (4-40) |
| Number of Rows | 3 |
| Voltage Rating | 300V |
| Backset Spacing | - |
| Connector Style | D-Sub, High Density |
| Contact Material | Phosphor Bronze |
| Ingress Protection | - |
| Dielectric Material | Polyamide (PA6T), Nylon 6T |
| Number of Positions | 15 |
| Current Rating (Amps) | 2A |
| Operating Temperature | -55°C ~ 105°C |
| Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish Thickness | Flash |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 1 (DE, E) High Density |
In Stock 43415 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.80 | $3.72 | $3.65 |
