Image is for reference only , See Product Specifications
180-M62-103L021
| Manufacturers: | NorComp Inc. |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 180-M62-103L021 |
| Description: | CONN D-SUB HD PLUG 62POS PNL MNT |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NorComp Inc. |
| Product Category | D-Sub Connectors |
| Color | Black |
| Series | 180-M, M Series |
| Features | Grounding Indents, Shielded |
| Packaging | Tray |
| Wire Gauge | 24-28 AWG |
| Part Status | Active |
| Termination | Solder Cup |
| Contact Form | Machined |
| Contact Type | Signal |
| Mounting Type | Panel Mount |
| Connector Type | Plug, Male Pins |
| Contact Finish | Gold |
| Flange Feature | Cable Side (4-40) |
| Number of Rows | 3 |
| Voltage Rating | - |
| Backset Spacing | - |
| Connector Style | D-Sub, High Density |
| Contact Material | Brass |
| Ingress Protection | - |
| Dielectric Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Number of Positions | 62 |
| Current Rating (Amps) | 5A |
| Operating Temperature | -55°C ~ 105°C |
| Shell Material, Finish | Steel, Nickel Plated |
| Contact Finish Thickness | Flash |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 4 (DC, C) High Density |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $13.18 | $12.92 | $12.66 |
