Image is for reference only , See Product Specifications
SA-7010TB
| Manufacturers: | Nidec Copal Electronics |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | SA-7010TB |
| Description: | SWITCH ROTARY DIP BCD 100MA 5V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Nidec Copal Electronics |
| Product Category | DIP Switches |
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.283" (7.20mm) |
| Series | SA-7000 |
| Circuit | BCD |
| Features | - |
| Washable | No |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Actuator Type | Rotary for Tool |
| Body Material | Polyphenylene Sulfide (PPS) |
| Mounting Type | Surface Mount |
| Actuator Level | Flush, Recessed |
| Contact Finish | Gold |
| Voltage Rating | 5VDC |
| Electrical Life | 10,000 Steps |
| Mechanical Life | - |
| Contact Material | Copper Alloy |
| Termination Style | Gull Wing |
| Height Above Board | 0.118" (3.00mm) |
| Number of Positions | 10 |
| Current Rating (Amps) | 100mA |
| Operating Temperature | -40°C ~ 85°C |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.01 | $1.97 | $1.93 |
