S-8031
| Manufacturers: | Nidec Copal Electronics |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | S-8031 |
| Description: | SW ROTARY DIP OCT COMP 100MA 5V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Nidec Copal Electronics |
| Product Category | DIP Switches |
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.283" (7.20mm) |
| Series | S-8000 |
| Circuit | Octal Complement |
| Features | - |
| Washable | Yes |
| Packaging | Bulk |
| Part Status | Active |
| Actuator Type | Rotary for Tool |
| Body Material | Polybutylene Terephthalate (PBT) |
| Mounting Type | Through Hole, Right Angle |
| Actuator Level | Flush, Recessed |
| Contact Finish | Gold |
| Voltage Rating | 5VDC |
| Electrical Life | 10,000 Steps |
| Mechanical Life | - |
| Contact Material | Copper Alloy |
| Termination Style | PC Pin |
| Height Above Board | 0.283" (7.20mm) |
| Number of Positions | 8 |
| Current Rating (Amps) | 100mA |
| Operating Temperature | -25°C ~ 70°C |
In Stock 983 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.91 | $2.85 | $2.79 |
