Image is for reference only , See Product Specifications
CHS-06TA1
| Manufacturers: | Nidec Copal Electronics |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | CHS-06TA1 |
| Description: | SWITCH SLIDE DIP SPST 100MA 6V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Nidec Copal Electronics |
| Product Category | DIP Switches |
| Pitch | 0.050" (1.27mm), Half |
| Length | 0.362" (9.20mm) |
| Series | CHS |
| Circuit | SPST |
| Features | - |
| Washable | No |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Actuator Type | Slide (Standard) |
| Body Material | Polyphenylene Sulfide (PPS) |
| Mounting Type | Surface Mount |
| Actuator Level | Flush, Recessed |
| Contact Finish | Gold |
| Voltage Rating | 6VDC |
| Electrical Life | 2,000 Cycles |
| Mechanical Life | - |
| Contact Material | Copper Alloy |
| Termination Style | J Lead |
| Height Above Board | 0.098" (2.50mm) |
| Number of Positions | 6 |
| Current Rating (Amps) | 100mA |
| Operating Temperature | -40°C ~ 85°C |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.54 | $1.51 | $1.48 |
