Image is for reference only , See Product Specifications
UXY1H232MHW
| Manufacturers: | Nichicon |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | UXY1H232MHW |
| Description: | 50V 2300UF 20% VIBE RES LEADED |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Nichicon |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | UXY |
| Ratings | - |
| Packaging | Bulk |
| Tolerance | ±20% |
| Capacitance | 2300µF |
| Part Status | Active |
| Applications | Automotive |
| Lead Spacing | 0.295" (7.50mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Voltage - Rated | 50V |
| Lifetime @ Temp. | 3000 Hrs @ 135°C |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Height - Seated (Max) | 1.299" (33.00mm) |
| Operating Temperature | -40°C ~ 135°C |
| Surface Mount Land Size | - |
| Ripple Current @ Low Frequency | 3.788A @ 120Hz |
| Ripple Current @ High Frequency | 5.05A @ 100kHz |
| ESR (Equivalent Series Resistance) | 29mOhm @ 100kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.51 | $4.42 | $4.33 |
