Image is for reference only , See Product Specifications
UUG0J103MNQ1ZD
| Manufacturers: | Nichicon |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | UUG0J103MNQ1ZD |
| Description: | CAP ALUM 10000UF 20% 6.3V SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Nichicon |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | UUG |
| Ratings | - |
| Packaging | Tray |
| Tolerance | ±20% |
| Capacitance | 10000µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | - |
| Polarization | Polar |
| Mounting Type | Surface Mount |
| Package / Case | Radial, Can - SMD |
| Voltage - Rated | 6.3V |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Height - Seated (Max) | 0.886" (22.50mm) |
| Operating Temperature | -40°C ~ 85°C |
| Surface Mount Land Size | 0.752" L x 0.752" W (19.10mm x 19.10mm) |
| Ripple Current @ Low Frequency | 2A @ 120Hz |
| Ripple Current @ High Frequency | 2.3A @ 10kHz |
| ESR (Equivalent Series Resistance) | - |
In Stock 185 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.10 | $2.06 | $2.02 |
