Image is for reference only , See Product Specifications
MC9S08SH8MPJ
| Manufacturers: | NXP USA Inc. |
|---|---|
| Product Category: | Embedded - Microcontrollers |
| Data Sheet: | MC9S08SH8MPJ |
| Description: | IC MCU 8BIT 8KB FLASH 20DIP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NXP USA Inc. |
| Product Category | Embedded - Microcontrollers |
| Speed | 40MHz |
| Series | S08 |
| RAM Size | 512 x 8 |
| Core Size | 8-Bit |
| Packaging | Tube |
| EEPROM Size | - |
| Part Status | Obsolete |
| Peripherals | LVD, POR, PWM, WDT |
| Connectivity | I²C, LINbus, SCI, SPI |
| Mounting Type | Through Hole |
| Number of I/O | 17 |
| Core Processor | S08 |
| Package / Case | 20-DIP (0.300", 7.62mm) |
| Data Converters | A/D 12x10b |
| Oscillator Type | Internal |
| Base Part Number | MC9S08SH8 |
| Program Memory Size | 8KB (8K x 8) |
| Program Memory Type | FLASH |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Supplier Device Package | 20-DIP |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
In Stock 32 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.85 | $3.77 | $3.70 |
