Image is for reference only , See Product Specifications
FBA06T24L
| Manufacturers: | NMB Technologies Corporation |
|---|---|
| Product Category: | DC Brushless Fans (BLDC) |
| Data Sheet: | FBA06T24L |
| Description: | FAN AXIAL 60X15MM 24VDC WIRE |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NMB Technologies Corporation |
| Product Category | DC Brushless Fans (BLDC) |
| RPM | 3200 RPM |
| Noise | 24.0 dB |
| Width | 15.00mm |
| Series | FBA |
| Weight | 0.111 lb (50.35 g) |
| Air Flow | 12.0 CFM (0.336m³/min) |
| Fan Type | Tubeaxial |
| Features | - |
| Approvals | CSA, UL |
| Part Status | Obsolete |
| Termination | 2 Wire Leads |
| Bearing Type | Hydro-wave (HWB) |
| Power (Watts) | 1.34W |
| Voltage Range | 14 ~ 27.6VDC |
| Static Pressure | 0.110 in H2O (27.4 Pa) |
| Voltage - Rated | 24VDC |
| Lifetime @ Temp. | - |
| Material - Blade | - |
| Material - Frame | - |
| Size / Dimension | Square - 60mm L x 60mm H |
| Ingress Protection | - |
| Current Rating (Amps) | 0.056A |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
