WT25L
| Manufacturers: | NKK Switches |
|---|---|
| Product Category: | Toggle Switches |
| Data Sheet: | WT25L |
| Description: | SWITCH TOGGLE DPDT 10A 125V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NKK Switches |
| Product Category | Toggle Switches |
| Series | WT |
| Circuit | DPDT |
| Features | Epoxy Sealed Terminals |
| Packaging | Bulk |
| Part Status | Active |
| Illumination | Non-Illuminated |
| Actuator Type | Standard Round |
| Mounting Type | Panel Mount |
| Bushing Thread | M12 x 1 |
| Actuator Length | 17.50mm |
| Electrical Life | 15,000 Cycles |
| Switch Function | On-Mom |
| Actuator Material | Brass, Chrome Plated |
| Termination Style | Wire Leads |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Voltage Rating - AC | 125V |
| Voltage Rating - DC | 30V |
| Current Rating (Amps) | 10A (AC/DC) |
| Operating Temperature | -30°C ~ 70°C |
| Panel Cutout Dimensions | Circular - 12.50mm Dia |
| Illumination Type, Color | - |
| Illumination Voltage (Nominal) | - |
In Stock 44 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $32.05 | $31.41 | $30.78 |
