Image is for reference only , See Product Specifications
ND3KC16H
| Manufacturers: | NKK Switches |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | ND3KC16H |
| Description: | SW ROTARY DIP HEX COMP 100MA 5V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NKK Switches |
| Product Category | DIP Switches |
| Pitch | 0.050" (1.27mm), Half |
| Length | 0.320" (8.13mm) |
| Series | ND3 |
| Circuit | Hexadecimal Complement |
| Features | Epoxy Sealed Terminals |
| Washable | Yes |
| Packaging | Tray |
| Part Status | Active |
| Actuator Type | Rotary with Shaft |
| Body Material | Polyamide (PA), Nylon, Glass Filled |
| Mounting Type | Surface Mount, Right Angle |
| Actuator Level | Raised |
| Contact Finish | Gold |
| Voltage Rating | 5VDC |
| Electrical Life | 20,000 Steps |
| Mechanical Life | 20,000 Steps |
| Contact Material | Beryllium Copper |
| Termination Style | Gull Wing |
| Height Above Board | 0.316" (8.03mm) |
| Number of Positions | 16 |
| Current Rating (Amps) | 100mA |
| Operating Temperature | -25°C ~ 85°C |
In Stock 8 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $5.90 | $5.78 | $5.67 |
