Image is for reference only , See Product Specifications
M2015S2S1W01
| Manufacturers: | NKK Switches |
|---|---|
| Product Category: | Toggle Switches |
| Data Sheet: | M2015S2S1W01 |
| Description: | SWITCH TOGGLE SPDT 6A 125V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NKK Switches |
| Product Category | Toggle Switches |
| Series | M |
| Circuit | SPDT |
| Features | Epoxy Sealed Terminals |
| Packaging | Bulk |
| Part Status | Active |
| Illumination | Non-Illuminated |
| Actuator Type | Standard Round |
| Mounting Type | Panel Mount |
| Bushing Thread | 1/4-40 |
| Actuator Length | 5.08mm |
| Electrical Life | 25,000 Cycles |
| Switch Function | On-Mom |
| Actuator Material | Brass, Chrome Plated |
| Termination Style | Solder Lug |
| Ingress Protection | - |
| Voltage Rating - AC | 125V |
| Voltage Rating - DC | 30V |
| Current Rating (Amps) | 6A (AC), 3A (DC) |
| Operating Temperature | -30°C ~ 85°C |
| Panel Cutout Dimensions | Circular - 6.50mm Dia |
| Illumination Type, Color | - |
| Illumination Voltage (Nominal) | - |
In Stock 60 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.83 | $4.73 | $4.64 |
