Image is for reference only , See Product Specifications
M2012SS1G45
| Manufacturers: | NKK Switches |
|---|---|
| Product Category: | Toggle Switches |
| Data Sheet: | M2012SS1G45 |
| Description: | SWITCH TOGGLE SPDT 0.4VA 28V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NKK Switches |
| Product Category | Toggle Switches |
| Series | M |
| Circuit | SPDT |
| Features | Epoxy Sealed Terminals |
| Packaging | Bulk |
| Part Status | Active |
| Illumination | Non-Illuminated |
| Actuator Type | Standard Round |
| Mounting Type | Panel Mount, Right Angle, Vertical |
| Bushing Thread | 1/4-40 |
| Actuator Length | 10.50mm |
| Electrical Life | 50,000 Cycles |
| Switch Function | On-On |
| Actuator Material | Brass, Chrome Plated |
| Termination Style | PC Pin |
| Ingress Protection | - |
| Voltage Rating - AC | 28V |
| Voltage Rating - DC | 28V |
| Current Rating (Amps) | 0.4VA (AC/DC) |
| Operating Temperature | -30°C ~ 85°C |
| Panel Cutout Dimensions | Circular - 6.50mm Dia |
| Illumination Type, Color | - |
| Illumination Voltage (Nominal) | - |
In Stock 100 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $6.12 | $6.00 | $5.88 |
