Image is for reference only , See Product Specifications
JS0208AP4
| Manufacturers: | NKK Switches |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | JS0208AP4 |
| Description: | SWITCH SLIDE DIP SPST 25MA 24V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NKK Switches |
| Product Category | DIP Switches |
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.837" (21.26mm) |
| Series | JS |
| Circuit | SPST |
| Features | - |
| Washable | No |
| Packaging | Bulk |
| Part Status | Active |
| Actuator Type | Slide (Standard) |
| Body Material | Polyamide (PA), Nylon, Glass Filled |
| Mounting Type | Surface Mount |
| Actuator Level | Raised |
| Contact Finish | Gold |
| Voltage Rating | 24VDC |
| Electrical Life | 2,000 Cycles |
| Mechanical Life | 2,000 Cycles |
| Contact Material | Beryllium Copper |
| Termination Style | Gull Wing |
| Height Above Board | 0.170" (4.33mm) |
| Number of Positions | 8 |
| Current Rating (Amps) | 25mA |
| Operating Temperature | -20°C ~ 70°C |
In Stock 45 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.78 | $2.72 | $2.67 |
Request Quote
