Image is for reference only , See Product Specifications
JL15SKSDDP2
| Manufacturers: | NKK Switches |
|---|---|
| Product Category: | Tactile Switches |
| Data Sheet: | JL15SKSDDP2 |
| Description: | SWITCH TACTILE SPST-NO 0.05A 24V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | NKK Switches |
| Product Category | Tactile Switches |
| Series | JL |
| Circuit | SPST-NO |
| Outline | 22.00mm x 22.00mm |
| Features | - |
| Packaging | Tray |
| Part Status | Active |
| Illumination | Illuminated |
| Actuator Type | Square Button |
| Mounting Type | Through Hole |
| Switch Travel | 0.75mm |
| Mechanical Life | 1,000,000 Cycles |
| Operating Force | 300gf |
| Switch Function | Off-Mom |
| Actuator Material | Polycarbonate (PC) |
| Termination Style | PC Pin |
| Ingress Protection | - |
| Actuator Orientation | Top Actuated |
| Operating Temperature | -25°C ~ 50°C |
| Contact Rating @ Voltage | 0.05A @ 24VDC |
| Illumination Type, Color | LED, Amber |
| Actuator Length, Right Angle | - |
| Illumination Voltage (Nominal) | 4 VDC |
| Actuator Height off PCB, Vertical | 7.85mm |
In Stock 29 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $19.69 | $19.30 | $18.91 |
