ADP1761ACPZ-1.2-R7
| Manufacturers: | NA |
|---|---|
| Product Category: | PMIC - Voltage Regulators - Linear |
| Data Sheet: | ADP1761ACPZ-1.2-R7 |
| Description: | IC REG LINEAR 1.2V 1A 16LFCSP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Analog Devices, Inc. |
| Product Category | PMIC - Voltage Regulators - Linear |
| PSRR | 67dB ~ 35dB (10kHz ~ 1MHz) |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Output Type | Fixed |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 16-WFQFN Exposed Pad |
| Base Part Number | ADP1761 |
| Control Features | Enable, Power Good, Soft Start |
| Current - Output | 1A |
| Protection Features | Current Limit, Thermal Overload |
| Number of Regulators | 1 |
| Output Configuration | Positive |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Voltage - Input (Max) | 1.98V |
| Voltage Dropout (Max) | 0.053V @ 1A |
| Current - Supply (Max) | 11mA |
| Voltage - Output (Max) | - |
| Supplier Device Package | 16-LFCSP-WQ (3x3) |
| Current - Quiescent (Iq) | 8mA |
| Voltage - Output (Min/Fixed) | 1.2V |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.38 | $4.29 | $4.21 |
