Image is for reference only , See Product Specifications
AD9684BBPZ-500
| Manufacturers: | NA |
|---|---|
| Product Category: | Data Acquisition - Analog to Digital Converters (ADC) |
| Data Sheet: | AD9684BBPZ-500 |
| Description: | IC ADC 14BIT PIPELINED 196BGA |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Analog Devices, Inc. |
| Product Category | Data Acquisition - Analog to Digital Converters (ADC) |
| Series | - |
| Features | - |
| Packaging | Tray |
| Input Type | Differential |
| Part Status | Active |
| Architecture | Pipelined |
| Configuration | S/H-ADC |
| Mounting Type | Surface Mount |
| Data Interface | LVDS - Parallel |
| Number of Bits | 14 |
| Package / Case | 196-LFBGA Exposed Pad |
| Reference Type | External, Internal |
| Ratio - S/H:ADC | 1:1 |
| Base Part Number | AD9684 |
| Number of Inputs | 2 |
| Operating Temperature | -40°C ~ 85°C |
| Supplier Device Package | 196-BGA (12x12) |
| Number of A/D Converters | 1 |
| Voltage - Supply, Analog | 1.25V, 2.5V |
| Voltage - Supply, Digital | 1.22V ~ 1.28V |
| Sampling Rate (Per Second) | 500M |
In Stock 97 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $373.97 | $366.49 | $359.16 |
