Image is for reference only , See Product Specifications
0746420001
| Manufacturers: | Molex |
|---|---|
| Product Category: | Backplane Connectors - Specialized |
| Data Sheet: | 0746420001 |
| Description: | CONN RCPT COAX 8POS EDGE MNT |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Backplane Connectors - Specialized |
| Color | Natural |
| Pitch | 0.246" (6.25mm) |
| Series | 74642 |
| Features | Board Guide |
| Packaging | Tray |
| Part Status | Obsolete |
| Termination | Press-Fit |
| Mounting Type | Board Edge, Through Hole, Right Angle |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Number of Rows | 2 |
| Voltage Rating | 50V |
| Connector Style | Coax |
| Connector Usage | - |
| Number of Columns | 4 |
| Number of Positions | 8 |
| Current Rating (Amps) | 1A |
| Operating Temperature | -40°C ~ 85°C |
| Contact Layout, Typical | 8 Coax |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
