Image is for reference only , See Product Specifications
0732510134
| Manufacturers: | Molex |
|---|---|
| Product Category: | Coaxial Connectors (RF) |
| Data Sheet: | 0732510134 |
| Description: | CONN SMA PLUG STR 50 OHM SOLDER |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Coaxial Connectors (RF) |
| Series | 73251 |
| Features | - |
| Includes | 4 pcs - 1 Connector, 1 Contact, 1 Ferrule, 1 Heat Shrink |
| Impedance | 50Ohm |
| Packaging | Bulk |
| Body Finish | Nickel |
| Cable Group | RG-58, 141, 303 |
| Part Status | Active |
| Body Material | Brass |
| Housing Color | Silver |
| Mating Cycles | 500 |
| Mounting Type | Free Hanging (In-Line) |
| Connector Type | Plug, Male Pin |
| Fastening Type | Threaded |
| Insertion Loss | - |
| Voltage Rating | 500V |
| Connector Style | SMA |
| Frequency - Max | 18GHz |
| Number of Ports | 1 |
| Mounting Feature | - |
| Ingress Protection | - |
| Shield Termination | Crimp |
| Contact Termination | Solder |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Operating Temperature | -65°C ~ 165°C |
| Center Contact Plating | Gold |
| Center Contact Material | Beryllium Copper |
In Stock 520 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $6.74 | $6.61 | $6.47 |
