Image is for reference only , See Product Specifications
0536270274
| Manufacturers: | Molex |
|---|---|
| Product Category: | Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) |
| Data Sheet: | 0536270274 |
| Description: | CONN PLUG 20POS SMD GOLD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board) |
| Pitch | 0.025" (0.64mm) |
| Series | SlimStack 53627 |
| Features | Board Guide, Solder Retention |
| Packaging | Cut Tape (CT) |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Connector Type | Plug, Outer Shroud Contacts |
| Contact Finish | Gold |
| Number of Rows | 2 |
| Height Above Board | 0.354" (9.00mm) |
| Number of Positions | 20 |
| Mated Stacking Heights | 10mm, 16mm |
| Contact Finish Thickness | 10.0µin (0.25µm) |
In Stock 3164 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $3.57 | $3.50 | $3.43 |
