| Manufacturer |
Molex |
| Product Category |
FFC, FPC (Flat Flexible) Connectors |
| Pitch |
0.020" (0.50mm) |
| Series |
Easy-On 52892 |
| Features |
Solder Retention, Zero Insertion Force (ZIF) |
| Packaging |
Digi-Reel® |
| Part Status |
Active |
| Termination |
Solder |
| Housing Color |
White |
| Mating Cycles |
20 |
| Mounting Type |
Surface Mount, Right Angle |
| Actuator Color |
Brown |
| Cable End Type |
Straight, Tapered |
| Contact Finish |
Tin Bismuth |
| Flat Flex Type |
FFC, FPC |
| Voltage Rating |
50V |
| Locking Feature |
Flip Lock |
| Contact Material |
Phosphor Bronze |
| Actuator Material |
Polyphenylene Sulfide (PPS), Glass Filled |
| FFC, FCB Thickness |
0.30mm |
| Height Above Board |
0.079" (2.00mm) |
| Dielectric Material |
Polyamide (PA), Nylon, Glass Filled |
| Number of Positions |
24 |
| Current Rating (Amps) |
0.5A |
| Operating Temperature |
-40°C ~ 85°C |
| Connector/Contact Type |
Contacts, Bottom |
| Contact Finish Thickness |
39.4µin (1.00µm) |
| Material Flammability Rating |
UL94 V-0 |
