Image is for reference only , See Product Specifications
0522070960
| Manufacturers: | Molex |
|---|---|
| Product Category: | FFC, FPC (Flat Flexible) Connectors |
| Data Sheet: | 0522070960 |
| Description: | CONN FFC FPC TOP 9POS 1.00MM R/A |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | FFC, FPC (Flat Flexible) Connectors |
| Pitch | 0.039" (1.00mm) |
| Series | 52207 |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Packaging | Digi-Reel® |
| Part Status | Active |
| Termination | Solder |
| Housing Color | - |
| Mating Cycles | 30 |
| Mounting Type | Surface Mount, Right Angle |
| Actuator Color | - |
| Cable End Type | Tapered |
| Contact Finish | Gold |
| Flat Flex Type | FFC, FPC |
| Voltage Rating | 125V |
| Locking Feature | Slide Lock |
| Contact Material | Phosphor Bronze |
| Actuator Material | Polyphenylene Sulfide (PPS) |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.106" (2.70mm) |
| Dielectric Material | Polyamide (PA46), Nylon 4/6 |
| Number of Positions | 9 |
| Current Rating (Amps) | 1A |
| Operating Temperature | -30°C ~ 85°C |
| Connector/Contact Type | Contacts, Top |
| Contact Finish Thickness | 3.94µin (0.10µm) |
| Material Flammability Rating | UL94 V-0 |
In Stock 2985 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
