Image is for reference only , See Product Specifications
0399200304
| Manufacturers: | Molex |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 0399200304 |
| Description: | TERM BLK 4P SIDE ENTRY 15MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Black |
| Pitch | 0.591" (15.00mm) |
| Series | Eurostyle 39920 |
| Current | 115A |
| Voltage | 600V |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | 1-8 AWG |
| Part Status | Active |
| Screw Thread | 1/4-28 |
| Mounting Type | Through Hole |
| Torque - Screw | 3.95 Nm (35 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Rising Cage Clamp |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Thermoplastic |
| Positions Per Level | 4 |
| Operating Temperature | -40°C ~ 130°C |
| Clamp Material - Plating | Brass - Nickel Plated |
| Screw Material - Plating | Bronze - Tin Plated |
| Contact Material - Plating | Copper - Tin Plated |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $12.61 | $12.36 | $12.11 |
